GB Standard Portable Charger – Smart Connected

Product Overview

The GB Standard Portable Charger – Smart Connected Version is a portable AC charger for electric vehicles fitted with the GB/T interface. It pairs a white GB-standard gun with a compact control box that adds adjustable current, a display and reservation charging, giving owners of GB-standard vehicles more control than a basic plug-and-charge unit.

Two variants cover 16A (3.5kW, adjustable 8–16A) and 32A (7.0kW, adjustable 8–32A), running on single-phase AC220V at 50Hz. Manufactured in our IATF 16949-certified Wenzhou factory on our own PCB designs, it is offered to distributors and OEM/ODM buyers serving GB-standard vehicle markets.

Key Features & Advantages

GB Standard Interface

The charger uses the GB/T interface required by the Chinese EV market, so it connects directly to GB-standard vehicles without adapters. The white gun body measures 235×58×65mm and pairs with the same compact control box used across the range. For background on connector families, see our guide to global charging connector standards.

Adjustable 8–16A / 8–32A Current

Users can reduce the charging current to suit the available circuit, with the 32A model adjustable from 8A to 32A and the 16A model from 8A to 16A. This flexibility helps on shared or older supplies.

Display and Reservation Charging

An on-device screen shows charging status and settings, while reservation charging lets users schedule sessions for a chosen time. Together they add convenience without requiring a smartphone or network link.

IP65 Control Box and 5-Metre Cable

The IP65 control box is rated for -30°C to +50°C operation, and the standard 5-metre cable can be customised for volume orders. The unit runs on single-phase AC220V at 50Hz.

Eight-Layer Safety Protection

Leakage, overvoltage, undervoltage, overcurrent, grounding, overtemperature, emergency-stop and short-circuit protection are built in, supporting safe operation in everyday home and fleet use.

Technical Specifications

Parameter	Value
Parameter	Value
Product Model	CREVC-GBT2G116, CREVC-GBT2G132
Charging Gun Dimensions	235mm(L)*58mm(W)*65mm(H)
Control Box Dimensions	235mm(L)*99mm(W)*52mm(H)
Charging Gun Color	White
Charging Plug Type	GB Standard Interface
Input Frequency	50Hz
Operating Temperature	-30°C~+50°C
Protection Level	IP65 (Control Box)
Total Product Length	5m (customizable length)
Rated Voltage	Single-phase AC220V
Rated Current	16A (8-16A adjustable), 32A (8-32A adjustable)
Rated Power	3.5kW, 7.0kW
Display Screen	Yes
Application Scenario	Personal on-board use
Charging Mode	1. Plug and Charge 2. Reservation Charging
Safety Design	Leakage protection, overvoltage protection, undervoltage protection, overcurrent protection, grounding protection, overtemperature protection, emergency stop protection, short circuit protection

Application Scenarios

Home Charging for GB-Standard EVs

Owners of GB-standard vehicles can charge from a suitable household supply with adjustable current and scheduled sessions. The display keeps the active settings visible.

Fleet and Dealer Programmes

Dealers and fleet operators can equip GB-standard vehicles with a portable charger that travels with each car. Reservation charging helps align sessions with cheaper power windows.

Distributor Line-Up

Distributors serving GB-standard markets can pair this model with related accessories such as the GB Standard AC charging gun cable to build a complete offering.

Frequently Asked Questions

Q: Which vehicles is this charger compatible with? A: It uses the GB/T interface and is intended for GB-standard vehicles. It is not designed for Type 2 (IEC 62196-2) or Type 1 (SAE J1772) vehicles.

Q: Can I adjust the charging current? A: Yes. The 16A variant is adjustable from 8A to 16A and the 32A variant from 8A to 32A, with the setting shown on the display.

Q: What is the warranty, MOQ and lead time? A: Standard warranty is 24 months. MOQ is 50 units for branded CREVCC products and 100 units for OEM/private-label orders, with a typical lead time of 30–45 days.

Request a Quote

The GB Standard Portable Charger – Smart Connected Version combines GB/T compatibility with adjustable current, a display and reservation charging for GB-standard vehicle markets. Contact us with your target current rating and branding needs for pricing and lead time.
